材 料：金属为不锈钢304 ,密封件材料为改性橡胶
温度范围:-40℃至100℃ ,短时可达120℃
防爆等级：Ex d IIC Gb/Ex e IIGB
材 料：金属为不锈钢304 ,密封件材料为改性橡胶
温度范围:-40℃至100℃ ,短时可达120℃
防爆等级：Ex d IIC Gb/Ex e IIGB
| 型号Item No. | 外螺纹F Dimension |
内螺纹G Dimension |
总长L mm |
外螺纹长L1 mm |
扳手尺寸 mm |
| REM-Exd-M/M 公制螺纹 Metric Thread | |||||
| REM-Exd-M20/M16 | M20xl.5 | M16xl.5 | 29 | 15 | 22 |
| REM-Exd-M25/M20 | M25xl.5 | M20xl.5 | 29 | 15 | 28 |
| REM-Exd-M32/M25 | M32xl.5 | M25xl.5 | 19.5 | 15 | 36 |
| REM-Exd-M40/M32 | M40xl.5 | M32xl.5 | 20 | 15 | 45 |
| REM-Exd-M50/M40 | M50xl.5 | M40xl.5 | 20 | 15 | 55 |
| REM-Exd-M63/M50 | M63xl.5 | M50xl.5 | 26 | 20 | 70 |
| REM-Exd-PG/PG PG螺纹PG Thread | |||||
| REM-Exd-PG11/PG09 | PG11 | PG9 | 19 | 15 | 20 |
| REM-Exd-PG13.5/PG11 | PG13.5 | PG11 | 19 | 15 | 22 |
| REM-Exd-PG16/PG13.5 | PG16 | PG13.5 | 19 | 15 | 24 |
| REM-Exd-PG21/PG16 | PG21 | PG16 | 19.5 | 15 | 30 |
| REM-Exd-PG29/PG21 | PG29 | PG21 | 19.5 | 15 | 40 |
| REM-Exd-PG36/PG29 | PG36 | PG29 | 20 | 15 | 50 |
| REM-Exd-PG42/PG36 | PG42 | PG36 | 25 | 20 | 58 |
| REM-Exd-PG48/PG42 | PG48 | PG42 | 26 | 20 | 65 |
