型号 |
螺牙规格 |
适应电缆 Φ |
螺纹外径 O.D. |
机板口径 Mounting |
螺纹长度 Length |
接合长度 Length |
板手 size |
包装 Pcs |
|
德制螺纹
|
100PCS | |||||||
| DIN-PG-7 | PG-7 | 6-8 | 12.5 | 12.5-12.8 | 5 | 15 | 15 | |
| DIN-PG-9 | PG-9 | 6-8 | 15.2 | 15.2-15.8 | 6 | 17 | 17 | |
| DIN-PG-9 | PG-9 | 8-10 | 15.2 | 15.2-15.8 | 6 | 17 | 17 | |
| DIN-PG-11 | PG-11 | 6-8 | 18.6 | 18.6-18.9 | 6 | 17 | 20 | |
| DIN-PG-11 | PG-11 | 8-10 | 18.6 | 18.6-18.9 | 6 | 17 | 20 | |
| DIN-PG-11 | PG-11 | 10-12 | 18.6 | 18.6-18.9 | 6 | 18 | 20 | |
| DIN-PG-13.5 | PG-13.5 | 12-14 | 20.4 | 20.4-20.7 | 7 | 19.5 | 24 | |
|
公制螺纹
|
100PCS | |||||||
| DIN-M12*1.5 | M12*1.5 | 6-8 | 12 | M12*1.5 | 5 | 15 | 15 | |
| DIN-M16S*1.5 | M16*1.5 | 6-8 | 16 | M16*1.5 | 6 | 17 | 17 | |
| DIN-M16*1.5 | M16*1.5 | 8-10 | 16 | M16*1.5 | 6 | 17 | 17 | |
| DIN-M18S*1.5 | M18*1.5 | 6-8 | 18 | M18*1.5 | 6 | 17 | 20 | |
| DIN-M18*1.5 | M18*1.5 | 8-10 | 18 | M18*1.5 | 6 | 17 | 20 | |
| DIN-M18D*1.5 | M18*1.5 | 10-12 | 18 | M18*1.5 | 6 | 18 | 20 | |
| DIN-M20*1.5 | M20*1.5 | 12-14 | 20 | M20*1.5 | 7 | 19.5 | 24 | |
| DIN-M25*1.5 | M25*1.5 | 14-18 | 25 | M25*1.5 | 7 | 32.5 | 30/34 | |
| DIN-M32*1.5 | M32*1.5 | 17-23 | 32 | M32*1.5 | 8 | 32.5 | 36/40 | 20PCS |
| DIN-M36*1.5 | M36*1.5 | 22-27 | 36 | M36*1.5 | 8 | 35 | 45/48 | |
| DIN-M40*1.5 | M40*1.5 | 26-33 | 40 | M40*1.5 | 9 | 35 | 50/55 | 5PCS |
| DIN-M50*1.5 | M50*1.5 | 32-41 | 50 | M50*1.5 | 9 | 37 | 58/65 | |
| DIN-M56*2.0 | M56*1.5 | 40-49 | 56 | M56*1.5 | 9 | 40 | 65/70 | |
| DIN-M63*1.5 | M63*1.5 | 48-57 | 63 | M63*1.5 | 10 | 40 | 75/80 | |
